MultiLevel Instruction Manual MENU structure
Param. Factory
Setting
Meaning
3.1.4.7.4.2 19 Page 4 / line 2: Delivered volume VT in liters
3.1.4.7.4.3 20 Page 4 / line 3: Delivered volume V15 in liters
3.1.4.7.5.1 23 Page 5 / line 1: CTL
3.1.4.7.5.2 24 Page 5 / line 2: API table for the product
3.1.4.7.5.3 31 Page 5 / line 3: Product density in kg/m³
3.1.4.7.6.1 28
3.1.4.7.6.2 29
3.1.4.7.6.3 30 Page 6 / line 3: Delivered mass in kg
3.1.4.7.7.1 42 Page 7 / line 1: Preset amount in liters (VT or V15)
3.1.4.7.7.2 43 Page 7 / line 2: Remaining volume until preset in liters
3.1.4.7.7.3 44 Page 7 / line 3: Remaining time until preset in min.
3.1.4.7.8.1 46 Page 8 / line 1: Current NOMIX status of the compartment
3.1.4.7.8.2 36 Page 8 / line 2: Product name
3.1.4.7.8.3 38 Page 8 / line 3: Wet leg sensor status
Table showing all available help displays and their numbers:
ID Description Example
>123456789012345678901<
0 Blank line
1 Roll (Y) >Roll -0,71 ° <
2 Min. roll (compartment) >C.min.roll -3,00 ° <
3 Max. roll (compartment) >C.max.roll +3,00 ° <
4 Min. roll (total) >Tl.min.roll -5,00 ° <
5 Max. roll (total) >Tl.max.roll +5,00 ° <
6 Pitch (X) >Pitch 2,51 ° <
7 Min. pitch (compartment) >C.min.pitch -3,00 ° <
8 Max. pitch (compartment) >C.max.pitch +3,00 ° <
9 Min. pitch (total) >Tl.min.pitch -5,00 ° <
10 Max. pitch (total) >Tl.max.pitch +5,00 ° <
11 Fill height [mm] >Fill height 1234,56 mm<
12 Measured value of level sensor (raw data)
[mm]
>Levelsens. 1234,56 mm<
13 Current date + current time >16.09.2004 10:45:23<
14 Current time >Time 10:45:23<
15 Current date >Date 16.09.2004<
16 Current product temperature [° Celsius] >Curr. temp. +23,4 °C<
17 Current product temperature [°Fahrenheit] >Curr. temp. +74,1 °F<
18 Current product temperature [° Kelvin] >Curr. temp. +74,1 °K<
19 Volume VT >VT 123456,7 l <
20 Volume V15 >V15 123456,7 l <
21 Start time >Start 10:45:23<
22 Start date >Start 16.09.2004<
23 Current compensation factor CTL
24 API table used
25 Average product temperature [° Celsius] >Ave. temp. +23,4 °C<
26 Average product temperature [° Fahrenheit] >Ave. temp. +74,1 °F<
