JOG EXCITE: Service & Maintenance Manual - rev. 1.1
Page 9.17
MENU –A–
Par. AddressDescription Value Par. AddressDescription Value
PID mode (700/900) 1 A-59 1218PID min neg err 50
A-0 1200
PID mode (500) 0 A-100 1219Set Linear speed 0
A-1 1201PID ref sel 5 A-101 1220Set Acc Dec 100
A-2 1202PID fbk sel 4 A-102 1221Set Incline ref 0
A-3 1203PID digital ref 0 A-105 1222Def Linear speed 8
A-4 1204PID activat mode 0 A-106 1223Def Acc Dec 100
A-5 1205PID-Encoder sync 1 A-107 1224Def Incline ref 0
A-6 1206PID err sign rev 0 A-110 1225Pulley Ratio 200
A-7 1207PID Integ init en 0 A-111 1226Roller Diameter 91
A-8 1208PID update time 0
A-50 1209PID Prop gain 1
7
A-115 1227
DCMot EncTimeout
(AT driver SW ≥ 2.07)
15
A-51 1210PID Int tconst 1 150 A-116 1228Fan command dly 30
A-52 1211PID Deriv gain 1 0 50
A-53 1212PID Prop gain 2 0
A-117 1229ACMot EncToller
0(OFF)
A-54 1213PID Int tconst 2 9999 A-118 1230Check RunnerBand 10
A-55 1214PID Deriv gain 2 0 A-119 1231Check RunnerSpd 50
A-56 1215PID high limit 80 A-120 1232Curr clamp thr 200
A-57 1216PID low limit -80 A-121 1233Check RunnerDly 60
A-58 1217PID max pos err 50
MENU –C–
Par. Address Description Value Par. Address Description Value
C-0 800 Save parameters 0 C-41 805 Save pars to key 0
C-1 801 Recall param 0 C-100 806 Measure stator R 0
C-2 802 Load default 0 C-200 807 Reset AC Flag 0
C-20 803 Alarm clear 0 C-201 808 Reset DC Flag 0
C-40 804 Recall key prog 0
MENU –D–
Par. Address Description Value Par. Address Description Value
D-0 1 Output frequency 0 D-200 26 An in 1 cnf mon 0
D-1 2 Frequency ref 0 D-201 27 An in 1 monitor 0
D-2 3 Output current 0 D-202 28 An in 1 term mon 0
D-3 4 Output voltage 0 D-210 29 An in 2 cnf mon 0
D-4 5 DC link voltage 400 D-211 30 An in 2 monitor 0
D-5 6 Power factor 100 D-212 31 An in 2 term mon 0
D-6 7 Power [kW] 0 D-220 32 An in 3 cnf mon 0
D-7 8 Output speed 0 D-221 33 An in 3 monitor 0
D-8 9 Speed ref 0 D-222 34 An in 3 term mon 0
D-20 57 Actual speed 0 D-300 35 EncPulse/Sample 0
D-21 58 Actual incline user 0 D-301 36 Encoder freq 0
D-22 59 Actual ENC1 pos 0 D-302 37 Encoder speed 0
D-23 60 Crossed distance 0 D-350 38 Option 1 state 0
D-24 61 Reserved - D-351 39 Option 2 state 0
D-25 62 Flag status 0 D-352 40 Par port state 0
D-26 63 Actual ENC2 pos 0 D-400 41 PID reference 0
D-27 64 Actual speed from
Fenc
0 D-401 42 PID feedback 0
D-30 70 Reserved - D-402 43 PID error 0
D-50 10 Heatsink temp 0 D-403 44 PID integr comp 0
D-51 11 Drive OL 0 D-404 45 PID output 0
D-52 12 Motor OL 0 D-800 46 Error 1 0
D-53 13 Brake res OL 0 D-801 47 Error 2 0
D-100 14 Dig inp status 0 D-802 48 Error 3 0
D-101 15 Term inp status 0 D-803 49 Error 4 0
D-102 16 Vir dig inp stat 0 D-950 50 Drive rated cur 100
D-120 17 Exp dig inp stat 0 D-951 51 SW version 1\2 200h
