JOG EXCITE: Service & Maintenance Manual - rev. 1.1
Page 9.18
MENU –D–
Par. Address Description Value Par. Address Description Value
D-121 18 Exp term inp 0 D-952 52 SW version 1\2 80h
D-122 19 Exp Vir dig inp stat 0 D-953 53 power ident code 0h
D-150 20 Dig out status 0 D-954 54 param ident code 0h
D-151 21 Drv dig out sta 0 D-955 55 regul ident code 3/8h
D-152 22 Vir dig out sta 0 D-956 56 Startup id code 0h
D-170 23 Exp Dig out status 0 D-957 71 Drive type 2
D-171 24 Exp Drv dig out sta 0 D-999 99 Display test -
D-172 25 Exp Vir dig out sta 0
MENU –F–
Par. Address Description Value Par. Address Description Value
F-0 300 Motorpot ref 0 F-110 321 Frequency ref 10 0
F-10 301 Acc/Dec time mp 50 F-111 322 Frequency ref 11 0
F-11 302 Motorpot offset 0 F-112 323 Frequency ref 12 0
F-12 303 Mp output mode 0 F-113 324 Frequency ref 13 0
F-13 304 Mp auto save 1 F-114 325 Frequency ref 14 0
F-20 305 Max ref freq 1150 F-115 326 Frequency ref 15 0
F-21 306 Min ref freq 0 F-116 327 Jog frequency 10
F-50 307 Ref 1 channel 8 F-200 328 Ramp resolution 0
F-51 308 Ref 2 channel 0 F-201 329 Acc time 1 3000
F-60 309 MltFrq channel 1 3 F-202 330 Dec time 1 3000
F-61 310 MltFrq channel 2 3 F-203 331 Acc time 2 50
F-100 311 Frequency ref 0 0 F-204 332 Dec time 2 50
F-101 312 Frequency ref 1 0 F-205 333 Acc time 3 50
F-102 313 Frequency ref 2 0 F-206 334 Dec time 3 / FS 50
F-103 314 Frequency ref 3 0 F-207 335 Acc time 4 / Jog 50
F-104 315 Frequency ref 4 0 F-208 336 Dec time 4 / Jog 50
F-105 316 Frequency ref 5 0 F-250 337 Ramp S-shape 0
F-106 317 Frequency ref 6 0 F-260 338 Ramp extens src 0
F-107 318 Frequency ref 7 0 F-270 339 Jump amplitude 0
F-108 319 Frequency ref 8 0 F-271 340 Jump frequency 1 0
F-109 320 Frequency ref 9 0 F-272 341 Jump frequency 2 0
MENU –I–
Par. Address Description Value Par. Address Description Value
I-0 100 Dig input 1 cfg 1 I-313 140 An out 2 filter 0
I-1 101 Dig input 2 cfg 0 I-350 141 Exp an out 1 cfg 0
I-2 102 Dig input 3 cfg 0 I-351 142 Exp AnOut 1 offs 0
I-3 103 Dig input 4 cfg 0 I-352 143 Exp AnOut 1 gain 100
I-4 104 Dig input 5 cfg 0 I-353 144 Exp AnOut 1 filt 0
I-5 105 Dig input 6 cfg 0 I-400 145 Inp by serial en 0
I-6 106 Dig input 7 cfg 0 I-410 146 Exp in by ser en 0
I-7 107 Dig input 8 cfg 0 I-420 147 Out by serial en 0
I-50 108 Exp dig in 1 cfg 0 I-430 148 Exp OutBySer en 0
I-51 109 Exp dig in 2 cfg 0 I-450 149 An out by ser en 0
I-52 110 Exp dig in 3 cfg 0 I-500 150 Encoder enable 1
I-53 111 Exp dig in 4 cfg 0 I-501 151 Encoder ppr 720
I-100 112 Dig output 1 cfg 48 I-502 152 Enc channels cfg 1
I-101 113 Dig output 2 cfg 48 I-503 153 Enc spd mul fact 100
I-102 114 Dig output 3 cfg 48 I-504 154 Enc update time 0
I-103 115 Dig output 4 cfg 48 I-600 155 Serial link cfg 6
I-150 116 Exp DigOut 1 cfg 48 I-601 156 Serial link bps 4
I-151 117 Exp DigOut 2 cfg 48 I-602 157 Device address 1
I-200 118 An in 1 Type 1 I-603 158 Ser answer delay 1
I-201 119 An in 1 offset 0 I-604 159 Serial timeout 0
I-202 120 An in 1 gain 100 I-605 160 En timeout alm 1
I-203 121 An in 1 minimum 0 I-700 161 Option 1 type 0
I-204 122 An in 1 filter 1 I-701 162 Option 2 type 0
