JOG EXCITE: Service & Maintenance Manual - rev. 1.1
Page 9.19
MENU –I–
Par. Address Description Value Par. Address Description Value
I-210 123 An in 2 Type 1 I-750 163 SBI address 3
I-211 124 An in 2 offset 0 I-751 164 CAN baudrate 0
I-212 125 An in 2 gain 100 I-752 165 SBI Profibus mod 2
I-213 126 An in 2 minimum 0 I-753 166 SBI CAN mode 0
I-214 127 An in 2 filter 1 I-760 167 SBI to Drv W 0 0
I-220 128 An in 3 Type 1 I-761 168 SBI to Drv W 1 0
I-221 129 An in 3 offset 0 I-762 169 SBI to Drv W 2 0
I-222 130 An in 3 gain 100 I-763 170 SBI to Drv W 3 0
I-223 131 An in 3 minimum 0 I-764 171 SBI to Drv W 4 0
I-224 132 An in 3 filter 1 I-765 172 SBI to Drv W 5 0
I-300 133 Analog out 1 cfg 0 I-770 173 Drv to SBI W 0 1
I-301 134 An out 1 offset 0 I-771 174 Drv to SBI W 1 2
I-302 135 An out 1 gain 100 I-772 175 Drv to SBI W 2 3
I-303 136 An out 1 filter 0 I-773 176 Drv to SBI W 3 4
I-310 137 Analog out 2 cfg 2 I-774 177 Drv to SBI W 4 5
I-311 138 An out 2 offset 0 I-775 178 Drv to SBI W 5 6
I-312 139 An out 2 gain 100
MENU –P–
Par. Address Description Value Par. Address Description Value
P-0 400 Cmd source sel 3 P-281 446 Brake res value 150
P-1 401 RUN input config 0 P-282 447 Brake res power 5
P-2 402 Reversal enable 1 P-283 448 Br res thermal K 160
P-3 403 Safety 1 P-300 449 DC braking level 0
P-20 404 Mains voltage 220 P-301 450 DCB lev fac src 0
P-21 405 Mains frequency 60 P-302 451 DC braking freq 0
P-40 406 Motor rated curr 70 P-303 452 DC braking start 0
P-41 407 Motor pole pairs 2 P-304 453 DC braking stop 0
P-42 408 Motor power fact 78 P-320 454 Autocapture mode 0
P-43 409 Motor stator R 100 P-321 456 Autocapture Ilim 120
P-44 410 Motor cooling 1 P-322 457 Demagnetiz time 8
P-45 411 Motor thermal K 30 P-323 458 Autocap f scan 10
P-60 412 V/f shape 1 P-324 459 Autocap V scan 2
P-61 413 Max out voltage 230 P-325 460 Enc for FlyRes 0
P-62 414 Base frequency 600 P-326 461 Fre for FlyRes 0
P-63 415 V/f interm volt 115 P-340 462 Undervoltage thr 50
P-64 416 V/f interm freq 300 P-341 463 Max pwrloss time 0
P-80 417 Max output freq 100 P-342 464 UV alarm storage 1
P-81 418 Min output freq 0 P-360 465 OV prevention 0
P-100 419 Slip compensate 90 P-380 466 Autoreset attmps 0
P-101 420 Slip comp filter 3 P-381 467 Autoreset clear 10
P-120 421 Manual boost [%] 50 P-382 468 Autoreset delay 50
P-121 422 Boost factor src 0 P-383 469 Autores flt rly 1
P-122 423 Auto boost en 1 P-400 470 Ext fault mode 0
P-140 424 Magn curr gain 30 P-420 471 Volt reduc mode 0
P-160 425 Osc damping gain 10 P-421 472 V reduction fact 100
P-180 426 SW clamp enable 1 P-422 473 V fact mult src 0
P-200 427 Ramp CurLim mode 0 P-440 474 Frequency thr 1 0
P-201 428 Curr lim in ramp 170 P-441 475 Freq prog 1 hyst 5
P-202 429 En lim in steady 0 P-442 476 Frequency thr 2 0
P-203 430 Curr lim steady
-
P-443 477 Freq prog 2 hyst 5
P-204 431 Curr ctrl P-gain
-
P-460 478 Const speed tol 5
P-205 432 Curr ctrl I-gain
-
P-461 479 Const speed dl 1
P-206 433 Curr ctr feedfwd
-
P-480 480 Heatsnk temp lev 70
P-220 434 En DC link ctrl
-
P-481 481 Heatsnk temp hys 5
P-221 435 DC-lnk ctr Pgain
-
P-500 482 Switching freq 9
P-222 436 DC-lnk ctr Igain
-
P-501 483 Sw freq reduc en 0
P-223 437 DC-link ctr FF
-
P-520 484 Overmod max lev 0
