JOG EXCITE: Service & Maintenance Manual - rev. 1.1
Page 2.8
TRM-06: Belt motor cable
AT driver board - Motor
AT driver board
J5
Signal Color Motor
1 U Black 1
2 V Black 2
3 W Black 3
4 thermal cutout + Black 4
5 thermal cutout - Black 5
6 GND Black 6
internally
connected cable
TRM-08: Elevation motor cable
AT driver board – Elevation motor
AT driver board
J7
Signal Color Elevation motor
1 Motor - Black
2 Motor + Black
4 Gnd Black
5 +5 Vdc power supply for encoder Red
6 Pulses White
internally
connected cable
TRM-54: Limit switch cable
AT driver board – Limit switch
AT driver board
J8
Signal Color Limit switch
3 Contact White COM
8 Reference Brown NC
EAM2068: AT Driver board connecting cable
AT Power supply board – AT driver board
AT Power supply
board
XU2
Signal Color AT driver board
XU2
1 +12 Vdc power supply Blue 1
2 Gnd +12 Vdc Blue 2
3 + Sensing +5 Vdc Blue 3
4 - Sensing +5 Vdc Blue 4
5 +5 Vdc power supply Blue 5
6 Gnd +5 Vdc Blue 6
