JOG EXCITE: Service & Maintenance Manual - rev. 1.1
Page 2.9
EAM2069: AT Driver board connecting cable
AT Power supply board – AT driver board
AT Power supply
board
XU1
Signal Color AT driver board
XU1
1 +24 Vdc power supply Blue 1
2 Gnd +24 Vdc Blue 2
3 +5 Vdc power supply Blue 3
4 Gnd +5 Vdc Blue 4
