ENGLISH
User’s manual 4 UPS EVO DSP PLUS Modular
The height of the rack cabinet can be 1475 mm (30 rack unit) or 2010 mm (42 rack unit): it depends on how many
modules must be mounted inside (see Figure 1.3).
At the top of the front door, there is the Control Panel (see Figure 1.4).
Through the Control Panel, the user can easily understand the operation Mode, can read electrical measurements,
parameters, warnings, alarms, can set the functioning parameters and can send command messages.
Figure 1.3 – Cabinet Sizes
Figure 1.4 – Control Panel
Read this manual carefully before using the UPS EVO DSP Modular; it includes important
safety warnings and useful advices for correct use and installation.
UPS EVO DSP PLUS Modular is constantly being developed and improved: consequently, your unit may differ
somewhat from the description contained in this manual.
This manual includes the following models:
• UPS EVO DSP PLUS Modular from 20 to 300 KVA (PF 1,0)
In this manual UPS EVO DSP PLUS Modular will simply be referred to as UPS.
