CSA7404B, TDS7704B, TDS7404B, TDS7254B & TDS7154B Service Manual

CSA7000B & TDS7000B Test Record (cont.)

Instrument Serial Number: Certificate Number:

Temperature: RH %:

Date of Calibration: Technician:

Instrument performance test MaximumOutgoingIncomingMinimum

Input impedance

CH1 10 mV

CH1 100 mV

CH2 10 mV

CH2 100 mV

CH3 10 mV

CH3 100 mV

CH4 10 mV

CH4 100 mV

48.75 Ω

__________

51.25 Ω

Time base system

Long term sample rate, delay time, and internal

reference accuracy

9999.975 kHz __________ __________ 10000.025 kHz

Delta time measurement N/A __________ __________ ≤0.015 ns

Trigger system accuracy

Time accuracy f or pulse, glit ch, timeout, and

width, Hor. scal e 1 ns < time <1 s

Lower Limit

Upper Limit

4.75 ns

__________

5.25 ns

Probe com pensation output signal

Frequency 950 Hz __________ __________ 1.050 kHz

Voltage (difference) 400 mV __________ __________ 600 m V

Serial trigger (Opti on ST only)
