CSA7404B, TDS7704B, TDS7404B, TDS7254B & TDS7154B Service Manual
4-5
Brief Procedures
The Self Tests use internal routines to confirm basic functionality and proper
adjustment. No test equipment is required to do these test procedures.
The Functional Tests utilize the probe-compensation output at the front panel as
a test-signal source for further verifying that the instrument functions properly. A
BNC cable and a BNC-to-SMA adaptor or a TCA-BNC adapter are required to
do these test procedures.
Self Tests
This procedure uses internal routines to verify that the instrument functions and
was adjusted properly. No test equipment or hookups are required.
Equipment
required
None
Prerequisites Power on t he instrument and allow a 20 minute warm-up before doing
this procedure.
1. Verify that internal diagnostics pass: Do the following substeps to verify
passing of internal diagnostics.
a. Display the System diagnostics menu:
H If the instrument is in toolbar mode, click the MENU button to put
the instrument into menu bar mode.
H Pull down the Utilities menu and select Instrument Diagnos-
tics.... This displays the diagnostics control window.
b. Run the System Diagnostics:
H First disconnect any input signals from all four channels.
H Click the Run button in the diagnostics control window.
c. Wait: The internal diagnostics do an exhaustive verification of proper
instrument function. This verification may take several minutes. When
the verification is finished, the resulting status will appear in the
diagnostics control window.
Verify Internal Adjustment,
Self Compensation, and
Diagnostics
To Next Page
