CSA7404B, TDS7704B, TDS7404B, TDS7254B & TDS7154B Service Manual
7-1
Options
This section lists the standard and optional accessories available for the
instrument, as well as the product options.
Options
The following options can be ordered for the instrument:
Table 7- 1: Options
Option Description
TDS7704B
CSA7404B
TDS7404B
TDS7254B
TDS7154B
1K K4000 Instrument Cart n n n n n
1R Rack Mount Kit (includes: hardware and instructions for converting to rackmount configura-
tion)
n n n n n
FHD Front-panel removable hard disk drive. Floppy disk drive i s on the rear panel n n n n n
Acquisition memory
2M Long record lengt h: 2 Ms per channel, 8 Ms maximum n n n n n
3M Long record lengt h: 4 Ms per channel, 16 Ms maximum n n n n n
4M Long record lengt h: 8 M per channel, 32 Ms maximum n n n n n
5M Long record lengt h: 16 M per channel, 64 Ms maximum n n n n n
Power cords
A0 North American 115 V, 60 Hz power cord (standard) n n n n n
A1 Universal European 230 V, 50 Hz power cord n n n n n
A2 United Ki ngdom 230 V, 50 Hz power cord n n n n n
A3 Australian 230 V, 50 Hz power cord n n n n n
A5 Switzerland 230 V, 50 Hz power cord n n n n n
A6 Japan power cord n n n n n
A10 China 230 V, 50 Hz power cord n n n n n
A99 No power cord n n n n n
Softw are applications
DVI TDSDVI DVI compliance test application n n n n
DVD TDSDVD Optical storage analysis application n n n n n
ET3 TDSET3 Ethernet compliance test application n n n n n
J2 TDSDDM2 Disk Drive Measurements application n n n n n
