Specifications
1-26
CSA7404B, TDS7704B, TDS7404B, TDS7254B & TDS7154B Service Manual
Table 1- 11: Mechanical specifications
Characteristic Description
Weight
Benchtop configuration 17.7 kg (39 lbs) instrument only
19.1 kg (42 lbs) with fully accessorized pouch
38.8 kg (85.5 lbs) when packaged for domestic shipment
Rackmount kit 18.6 kg (41 lbs) rackmounted instrument
5.6 kg (12.5 lbs) kit packaged for dom estic shipment
Dimensions
Benchtop configuration With front cover Without front cover
278 mm (10.95 in) height
330 mm (13 in) with feet extended
455 mm (17.9 in) width
435 mm (17.13 in) depth
277 mm (10.9 in) height
330 mm (13 in) with feet extended
455 mm (17.9 in) width
426 mm (16.75 in) depth
Rackmount configuration (Option 1R) With rack handles Without rack handles
267 mm (10.5 in) height
502 mm (19.75 in) width
486 mm (19.13 in) depth
267 mm (10.5 in) height
482 mm (19 in) width
435 mm (17.13 in) depth
Cooling Fan-forced ai r circul ation with no air fil ter
Required clearances Top 0mm(0in)
Bottom 19 mm (0.75 in) minimum or
0 mm (0 in) when standing on feet, flip
stands down
Left side 76 mm (3 in)
Right side 76 mm (3 in)
Front 0mm(0in)
Rear 0 mm (0 in) on rear feet
Construction material Chassis parts are constructed of aluminum al loy, front panel is constructed of plastic
laminate, circuit boards are constructed of glass laminate, and the outer shell is
molded and textured from a polycarbonate/ABS blend
