Specifications
CSA7404B, TDS7704B, TDS7404B, TDS7254B & TDS7154B Service Manual
1- 5
Open Desktop. The instrument is built on a Microsoft Windows software
platform; the instrument application program starts automatically when you
apply power to the instrument. You can minimize the instrument application and
take full advantage of the built-in PC to run other applications. Moving
waveform images and data into other applications is as simple as a copy/paste
operation.
Dedicated Front Panel Controls. The front panel contains knobs and buttons to
provide immediate access to the most common instrument controls. Separate
vertical controls are provided for each channel. The same functions are also
available through the screen interf
ace.
Data Storage and I/O.The instrument has a
removeable hard disk drive, a
CD-RW, and a floppy disk drive that can be used for storage and retrieval of
data. The instrument has GPIB, USB, Centronics, and Ethernet ports for input
and output to other devices.
Online Help. The instrument has a complete online help system that covers all
features. The help system is context sensitive; help for the displayed control
window is automatically shown if you touch the help button. Graphical aids in
the help windows assist you in getting to the information you need. You can also
access the help topics thr ough a table of contents or index.
Specification Tables
Table 1- 2: Channel input and vertical specifications
Characteristic Description
Input channels Four
Input coupling Channel input is disconnected from input termination when using GND coupling.
DC 50 Ω and GND
Input impedance, DC coupled
50 Ω ±2.5% at 25 C (77 F), ± 0.2% over 0 to 50 C (122 F)
VSWR, typical
CSA7404B, TDS7404B, TDS7154B, &
TDS7254B
TDS7704B
1.5 for f
in
<1 GHz
1.7 for f
in
<2.5 GHz
2.0 for f
in
<4 GHz
< 100 mV/div ≥ 100 mV/div
1.5 for f
in
<2 GHz 1.1 for f
in
<2 GHz
2 for f
in
<3 GHz 1.2 for f
in
<3 GHz
2.5 for f
in
<6 GHz 1.3 for f
in
<6 GHz
