Tektronix CSA7404B Service Manual

Performance Tests
CSA7404B, TDS7704B, TDS7404B, TDS7254B & TDS7154B Service Manual
4-21
CSA7000B & TDS7000B Test Record
Photocopy this table and use it to record the performance test results for your
instrument.
CSA7000B & TDS7000B Test Record
Instrument Serial Number: Certificate Number:
Temperature: RH %:
Date of Calibration: Technician:
Instrument performance test Minimum Incoming Outgoing Maximum
DC voltage measurement accuracy (averaged), CSA7404B, TDS7404B, TDS7254B, & TDS7154B
CH1 2 mV Vert scale setting,
--5 Div position setting, +0.5 V offset
+ 512.79 mV __________ __________ + 519.21 mV
CH1 2 mV Vert scale setting,
+5 Div position setting, --0.5 V offset
-- 519.21 mV __________ __________ -- 512.79 mV
CH1 50 mV Vert scale setting,
--5 Div position setting, +0.5 V offset
+ 881.63 mV __________ __________ + 918.38 mV
CH1 50 mV Vert scale setting,
+5 Div position setting, --0.5 V offset
-- 918.38 V __________ __________ -- 881.63 mV
CH1 100 mV Vert scale setting,
--5 Div position setting, +4.8 V offset
+ 4.9393 V __________ __________ + 5. 0607 V
CH1 100 mV Vert scale setting,
+5 Div position setting, --4.8 V offset
-- 5.0607 V __________ __________ -- 4.9393 V
CH1 1.0 V Vert scale setting,
--5 Div position setting, +2.5 V offset
+ 4.1738 V __________ __________ + 4. 8263 V
CH1 1.0 V Vert scale setting,
+5 Div position setting, --2.5 V offset
-- 4.8263 V __________ __________ -- 4.1738 V
CH2 2 mV Vert scale setting,
--5 Div position setting, +0.5 V offset
+ 512.79 mV __________ __________ + 519.21 mV
CH2 2 mV Vert scale setting,
+5 Div position setting, --0.5 V offset
-- 519.21 mV __________ __________ -- 512.79 mV
CH2 50 mV Vert scale setting,
--5 Div position setting, +0.5 V offset
+ 881.63 mV __________ __________ + 918.38 mV
CH2 50 mV Vert scale setting,
+5 Div position setting, --0.5 V offset
-- 918.38 V __________ __________ -- 881.63 mV
CH2 100 mV Vert scale setting,
--5 Div position setting, +4.8 V offset
+ 4.9393 V __________ __________ + 5. 0607 V
CH2 100 mV Vert scale setting,
+5 Div position setting, --4.8 V offset
-- 5.0607 V __________ __________ -- 4.9393 V
CH2 1.0 V Vert scale setting,
--5 Div position setting, +2.5 V offset
+ 4.1738 V __________ __________ + 4. 8263 V
CH3 1.0 V Vert scale setting,
+5 Div position setting, --2.5 V offset
-- 4.8263 V __________ __________ -- 4.1738 V
