Removal and Installation Procedures
CSA7404B, TDS7704B, TDS7404B, TDS7254B & TDS7154B Service Manual
6-63
T-15 Torx
screw (3)
Nut and washer
Cables (4)
TekConnect ribbon cable
Figure 6- 41: Front panel combination assem bly removal (TDS7404B shown)
