Tektronix CSA7404B Service Manual

Specifications
CSA7404B, TDS7704B, TDS7404B, TDS7254B & TDS7154B Service Manual
1-13
Table 1- 3: Horizontal and acquisition system specifications (Cont.)
Characteristic Description
Maximum record length, HiRes mode, sample
rate ≤1.25 GS/s
2,000,000 points (1, 2, 3, or 4 channels)
Seconds/division range 50 ps/div to 10 s/div
Maximum FastFrame update rate, nominal 265,000 frames per second
Frame length and maximum number of frames Maximum number of frames for Sample or Peak Detect acquisition mode,
d
e
p
e
n
d
i
n
g
o
n
m
e
m
o
r
y
o
p
t
i
o
n
i
n
s
t
a
l
l
e
d
d
e
p
e
n
d
i
n
g
o
n
m
e
m
o
r
y
o
p
t
i
o
n
i
n
s
t
a
l
l
e
d
Frame length Maximum number of frames
50 points Standard: 648--5872
Option 2M: 2660--24088
Option 3M: 5321--48192
Option 4M: 5321--48192
Option 5M: 10644--96408
500 points Standard: 580--3560
Option 2M: 2381--14632
Option 3M: 4765--29272
Option 4M: 4765--29272
Option 5M: 9531--58552
5000 points Standard: 163--720
Option 2M: 669--2968
Option 3M: 1339--5936
Option 4M: 1339--5936
Option 5M: 2679--11880
50,000 points Standard: 19--80
Option 2M: 81--328
Option 3M: 163--656
Option 4M: 163--656
Option 5M: 327--1320
500,000 points Standard: 2--8
Option 2M: 8--32
Option 3M: 16--64
Option 4M: 16--64
Option 5M: 32--128
