Performance Tests
CSA7404B, TDS7704B, TDS7404B, TDS7254B & TDS7154B Service Manual
4-19
Table 4- 2: Test equipment (Cont.)
Item number and
description
PurposeExampleMinimum requirements
12. Generator, Sine-Wave
3
Instrument bandwidth ≤6 GHz:
5 kHz to at least the instrument
bandwidth. Variable amplitude from
60mVto2V
p-p
into 50 Ω. Frequency
error <2.0%
Rohde & Schwarz SMT06
with options 01 and 02
Checking analog bandwidth,
trigger sensitivity, sample-
rate, external clock, and
delay-time accuracy
Instrument bandwidth >6 GHz:
10 MHz to at least the instrument
bandwidth. Variable amplitude from
60 mV to 1.8 V
p-p
into 50 Ω. Frequen-
cy error <2.0%
Anritsu MG3692A Synthe-
sized CW Generator with
options 2x, 4, and 15
13. Meter, Level and Power
Sensor
Frequency range: 10 MH z to the
instrument bandwidth. Amplitude
range: 6 mV
p-p
to2V
p-p
Rohde & Schwarz NRVS and
NRV-Z102
Checking analog bandwidth
and Trigger Sensitivity
14. Splitter, Power Frequency range: DC to 4 GHz.
Tracking: >2.0%
Tektronix part number
015-0565-00
Checking delay between
channels
15. Adapter (four required) Male N-to-female BNC Tektronix part number
103-0045-00
Checking analog bandwidth
16. Adapter Female N-to-male BNC Tektronix part number
103-0058-00
Checking analog bandwidth
17. Adapter (three required) SMA female-to-fem ale Tektronix part number
015-1012-00
Checking the delay between
channels
18. Adapter (three required) SMA male-to-female BNC Tektronix part number
015-1018-00
Checking the delay between
channels
19. Adapter
(four required)
SMA male-to-BNC female TCA-BNC or TCA-SMA and
SMA male-to-BNC female
adapter (Tektronix part
number 015-0554-00 or
015-1018-00)
Signal interconnection
20. Pulse Generator 2 MHz, ≤150 ps rise time, 5 V out Fluke 9500B
1,2
Used to test delta time mea-
surement accuracy
21. Cable, Coaxial
(two required)
50 Ω, 20 in, male-to-male SMA
connectors
Tektronix part number
174-1427-00
Used to test delta time mea-
surement accuracy
22. Adapter SMA “T”, male to 2 SMA female Tektronix part number
015-1016-00
Used to test delta time mea-
surement accuracy
23. Adapter SMA female to BNC male Tektronix part number
015-0572-00
Used to test delta time mea-
surement accuracy
24. Adapter BNC male to female elbow Tektronix part number
103-0031-00
Used to test delta time mea-
surement accuracy
25. Termination (two re-
quired)
Short circuit, SMA connector, female Tektronix part number
015-1021-00
Used to test delta time mea-
surement accuracy
