Performance Tests
CSA7404B, TDS7704B, TDS7404B, TDS7254B & TDS7154B Service Manual
4-23
CSA7000B & TDS7000B Test Record (cont.)
Instrument Serial Number: Certificate Number:
Temperature: RH %:
Date of Calibration: Technician:
Instrument performance test MaximumOutgoingIncomingMinimum
DC voltage measurement accuracy (averaged), TDS7704B
CH1 2 mV Vert scale setting,
--5 Div position setting, +0.5 V offset
+511.99mV __________ __________ + 520.01 mV
CH1 2 mV Vert scale setting,
+5 Div position setting, --0.5 V offset
-- 520.01 mV __________ __________ -- 511.99 mV
CH1 50 mV Vert scale setting,
--5 Div position setting, +0.5 V offset
+ 879.75 mV __________ __________ + 920.25 mV
CH1 50 mV Vert scale setting,
+5 Div position setting, --0.5 V offset
-- 920.25 V __________ __________ -- 879.75 mV
CH1 100 mV Vert scale setting,
--5 Div position setting, +4.8 V offset
+ 4.9298 V __________ __________ + 5. 0702 V
CH1 100 mV Vert scale setting,
+5 Div position setting, --4.8 V offset
-- 5.0702 V __________ __________ -- 4.9298 V
CH1 1.0 V Vert scale setting,
--5 Div position setting, +2.5 V offset
+ 4.1475 V __________ __________ + 4. 8525 V
CH1 1.0 V Vert scale setting,
+5 Div position setting, --2.5 V offset
-- 4.8525 V __________ __________ -- 4.1475 V
CH2 2 mV Vert scale setting,
--5 Div position setting, +0.5 V offset
+511.99mV __________ __________ + 520.01 mV
CH2 2 mV Vert scale setting,
+5 Div position setting, --0.5 V offset
-- 520.01 mV __________ __________ -- 511.99 mV
CH2 50 mV Vert scale setting,
--5 Div position setting, +0.5 V offset
+ 879.75 mV __________ __________ + 920.25 mV
CH2 50 mV Vert scale setting,
+5 Div position setting, --0.5 V offset
-- 920.25 V __________ __________ -- 879.75 mV
CH2 100 mV Vert scale setting,
--5 Div position setting, +4.8 V offset
+ 4.9298 V __________ __________ + 5. 0702 V
CH2 100 mV Vert scale setting,
+5 Div position setting, --4.8 V offset
-- 5.0702 V __________ __________ -- 4.9298 V
CH2 1.0 V Vert scale setting,
--5 Div position setting, +2.5 V offset
+ 4.1475 V __________ __________ + 4. 8525 V
CH2 1.0 V Vert scale setting,
+5 Div position setting, --2.5 V offset
-- 4.8525 V __________ __________ -- 4.1475 V
CH3 2 mV Vert scale setting,
--5 Div position setting, +0.5 V offset
+511.99mV __________ __________ + 520.01 mV
CH3 2 mV Vert scale setting,
+5 Div position setting, --0.5 V offset
-- 520.01 mV __________ __________ -- 511.99 mV
