Tektronix TG8000

HD3G7 3 Gb/s SDI Video Generator module remote commands
HD3G7 3 Gb/s SD
I Video Generator module remote
commands
This section describes the commands used to remotely control the HD3G7 3 Gb/s
SDI Video Generator module. The commands are divided into the following
groups:
OUTPUT commands (Refer to the HD3G7 section of the TG8000 User
Manual for
restrictions on which standards are supported for each output
mode.)
SENSE com
mands
DIAGNOSTIC commands
OUTPUT commands
Use these commands control the output parameters of the module.
NOTE. T
he OUTPUT1 commands affect both of the BNC module connectors in
the same way. Output 1 is always identical to Output 2.
Command tree
:OUTPut1
:ALPHa
COPY
_YG|FF_0P|FF_10P|
FF_20P | FF_30P | FF_40P |
FF_50P | FF_60P | FF_70P |
FF_
80P | FF_90P FF_100P
:ANC
:OUTMode <DIS|CONT|SING>
:O
UTMode?
:PARIty
MAN|AUTO
:PARIty?
:LINe
<NR1>,<NR1>
:LINe?
:SAMple <NR1:sample>
:SAMple?
:DID <HEX>
:DID?
:SDID <HEX>
:SDID?
:DBN <HEX>
Draft
98 TG8000 Multiformat Test Signal Generator Programmer Manual
