Tektronix TG8000 Programmer's Manual

SDI7 Dual Channel SD/HD/3G SDI Video Generator module remote commands
Table 7: SDI7 horizontal offset ranges (cont.)
Standard / Frame rate
Range μs
(± 1 video line) Resolution
1080 23.98p / sF
37.074
.0135μs (74.18 MHz clock)
720 60p 22.222
.0135μs (75.25 MHz clock)
720 59.94p 22.244
.0135μs (74.18 MHz clock)
720 50p 26.667
.0135μs (75.25 MHz clock)
720 30p 44.444
.0135μs (75.25 MHz clock)
720 29.97p 44.489
.0135μs (74.18 MHz clock)
720 25p 53.333
.0135μs (75.25 MHz clock)
720 24p
55.555
.0135μs (75.25 MHz clock)
720 23.98p 55.611
.0135μs (74.18 MHz clock)
625 50i 64.000
.0741μs (13.5 MHz clock)
525 59.94i 63.556
.0741μs (13.5 MHz clock)
:SE
NSe<1|2>:CORRection:MDELay :HORizontal?
Returns the current horizontal timing offset of the selected outputs.
:SENSe<1|2>:CORRection:MD ELay:VERTical <NR1>
Sets the vertical timing offset of the selected outputs. The units are lines and
the range is"
1
/
2
frame. (See Table 8.)
Table 8: SDI7 Vertical offset ranges
Format (active lines) Range (lines)
1125-line (1080)
562
750-line (720)
375
625-line (576)
312
525-line (486)
262
:SENSe<1|2>:CORRection:MD ELay:VERTical?
Returns the current vertical timing offset of the selected output.
:SENSe<1|2>:CORRection:MD ELay:RELative ANALog|SERial
Sets the timing offset mode for the selected output. ANALog includes
correction for the delay through a standard D to A converter; SERial omits
this correction.
:SENSe<1|2>:CORRection:MD ELay:RELative
Returns the current timing offset mode for the selected output.
Draft
172 TG8000 Multiformat Test Signal Generator Programmer Manual
