Tektronix TG8000 Programmer's Manual

AVG7 Analog Video Generator module remote commands
Returns whethe
r or not a sync signal is multiplexed with the B and R signals
when a GBR signal is being output.
SENSE commands
Use these commands to set the timing offset of the output signals relative to the
internal reference signal (frame reset signal).
Refer to Operating Basics in the TG8000 User Manual for detailed information
about the setting range.
Command tree
:SENSe<n>
:CORRection
:MDELay
:HORizontal
<numeric_value>
:STEP
<numeric_value>
:VERTical <numeric_value>
:STEP
<numeric_value>
Command description
:SENSe1:CORRection:MDELay: HORizontal <numeric_value>
Sets the horizontal timing offset of the output signals. The timing resolution is
clock-cycle
s. The units are microseconds. You c an use UP, DOWN, or DEF
instead of the numeric value. If the argument exceeds the horizontal time
value, then the vertical offset is adjusted to accommodate the requested delay.
:SENSe1:CORRection:MDELay: HORizon
tal?
Returns the current horizontal timing offset of the output signals.
:SENSe1:CORRection:MDELay: HORizontal:STEP <numeric_value>
Sets the step increment used by the UP or D
OWN commands. The units are
microseconds. You can use M IN, MAX, or DEF instead of a numeric value.
:SENSe1:CORRection:MDELay: HORizontal:STEP?
Returns the current step increment.
:SENSe1:CORRection:MDELay: VERTical <numeric_value>
Sets the vertical timing offset of the output signals. The argument can be a
floating point value that is translated i
nto integer lines with a horizontal offset.
You can use UP, DOWN, or DEF instead of a numeric v alue.
:SENSe1:CORRection:MDELay: VERTical?
Returns the current vertical timing offset of the output signals.
Draft
TG8000 Multiformat Test Signal Generator Programmer Manual 51
