AGL7 Analog Genlock module remote commands
AGL7 Analog Ge
nlock module remote commands
This section
describes the commands used for the AGL7 Analog Genlock module
remote operation. The commands for the module are divided into the following
four groups:
INPUT commands
SOURCE commands
OUTPUT commands
SENSE commands
INPUT commands
Use these commands to set the input standard and input connector for the genlock
signal.
Command tree
:INPut
:REFerence
:STANdard NBURst | PBURst | N318M |
NSYNc | PSYNc | HDSYnc
:STATus?
:HDSYnc?
:SELect
REFerence | CW
:SOURce
INTernal | EXTe rnal
:CWAVE
:FRAMe
2.997 | 3.0 | 6.25 | 14.98 5
|15.0|0
:FREQuency
:LLOSs:ACTion INTernal | STAy
Command d escription
:INPut:REFerence:STANdard
NBURst|PBURst|N318M|NSYNc |PSYNc|HDSYnc
Selects the input standard expected at the REF connector. The choices are
NBURst (burst lock to NTSC black burst), PBURst (burst lock to PAL black
burst), N318M (burst lock to NTSC black burst with 10 field ID), NSYNc
(sync lock to NTSC black burst), PSYNc (sync lock to PAL black burst), and
HDSYnc (lock to HDTV trilevel sync).
:INPut:REFerence:STANdard ?
Returns the current input standard.
