Tektronix TG8000 Programmer's Manual

BG7 Black Generator module remote commands
SENSE command
s
Use these commands to adjust the timing offset of the BLACK outputs relative
to the internal reference signal (frame reset signal).
Refer to Operating Basics in the TG8000 User Manual for detailed information
about the timing offset range.
Command tr
ee
:SENSe<n>
:CORRection
:MDELay
:HORizontal <numeric_value>
:STEP
<numeric_value>
:VERTical <numeric_value>
:STEP
<numeric_value>
Command description
:SENSe<n>:CORRection:MDELa y:HORizontal <numeric_value>
Sets the horizontal timing offset of a specific BLACK output. The timing
resolution is clock-cycles. The unit is microseconds. You can use UP,
DOWN, or DEF instead of the numeric values. See page 2-2 for additional
detail on UP, DOWN, and DEF. If the argument exceeds the horizontal time
value, then the vertical offset is adjusted to accommodate the requested offset.
The <n> in the command represents the connector number. You can use any
connector number from 1 through 4.
:SENSe<n>:CORRection:MDELa y:HORizontal?
Returns the horizontal timing offset of a specific BLACK output. The <n> in
the command represents the connector number. You can use any connector
number from 1 through 4 .
:SENSe<n>:CORRection:MDELa y:HORizontal:STEP <numeric_value>
Sets the step increment used by the UP or DOWN commands. The unit is
microseconds. You can use UP, DOWN, or DEF instead of the numeric
values. The <n> in the command represents the connector number. You can
use any connector number from 1 through 4.
:SENSe<n>:CORRection:MDELa y:HORizontal:STEP?
Returns the step increment used by the UP or DOWN commands. The < n> in
the command represents the connector number. You can use any connector
number from 1 through 4 .
:SENSe<n>:CORRection:MDELa y:VERTical <numeric_value>
Draft
TG8000 Multiformat Test Signal Generator Programmer Manual 63
