ATG7 Analog Test Generator m odule remote commands
Returns the cur
rent output mode of the APL signal. You can specify only
"3" (SIGNAL connector) for the <n>.
:OUTPut<n>:A
PL:PERiod <numeric_value>
Sets the time interval between two signals when they are output in the bounce
modes. You c
an set the value from 0.5 seconds to 2.0 seconds in 0.5 seconds
steps. You can specify only "3" (SIGNAL connector) for the <n>.
:OUTPut<n>
:APL:PERiod
Returns the time interval between two signals when they are output in the
bounce mod
es. You can specify only "3" (SIGNAL connector) for the <n>.
SENSE commands
Use thes
e commands to adjust the timing offset of each o utput relative to the
internal reference signal (frame reset signal).
Refer t
o Operating Basics in the TG8000 User Manual for detailed information
about the timing offset range.
Command tree
:SENSe<n>
:CORRection
:MDELay
:HORizontal <numeric_value>
:STEP
<numeric_value>
:VE
RTical
<nu
meric_value>
:STEP
<numeric_value>
Command d escription
:SENSe<n>:CORRection:MDEL ay:HORizontal <numeric_value>
Sets the horizontal timing offset for the specified output. The timing resolution
is clock-cycles. The unit is microseconds. You can use UP, DOWN, or DEF
instead of the numeric values. See page 2-2 for additional detail on UP,
DOWN, and DEF. If the argument exceeds the horizontal time value, then the
vertical offset is adjusted to accommodate the requested offset. The <n> in
the command represents the output connector and you can specify from 1
through 4. "1" represents the BLACK 1 connector, "2" represents the BLACK
2 connector, "3" represents the SIGNAL connector, a nd "4" represents the
BARS connector.
:SENSe<n>:CORRection:MDEL ay:HORizontal?
Draft
42 TG8000 Multiformat Test Signal Generator Programmer Manual
