Tektronix TG8000

GPS7 GPS Synchronization and Timecode module remote commands
Table3: GPS7so
urce horizontal offset ranges
Standard / Frame rate Range (sample clock cycles)
NTSC ± 3432 (54 MHz clock)
PAL
± 3456 (54 MHz clock)
1080 60i
± 2200 (74.25 MHz clock)
1080 59.94i
± 2200 (74.18 MHz clock)
1080 50i
± 2640 (74.25 MHz clock)
1080 24 sF
± 2750 (74.25 MHz clock)
1080 23.9
8sF
± 2750 (74.18 MHz clock)
1080 30p
± 2200 (74.25 MHz clock)
1080 29.
97p
± 2200 (74.18 MHz clock)
1080 25
p
± 2640 (74.25 MHz clock)
1080 24
p
± 2750 (74.25 MHz clock)
1080 2
3.98p
± 2750 (74.18 MHz clock)
720 6
0p
± 1650 (74.25 MHz clock)
720 5
9.94p
± 1650 (74.18 MHz clock)
:SOURce:CORRection:MDELay :HORizontal?
Returns the current horizontal timing offset of the selected source.
:SOURce:CORRection:MDELay :HORizontal:STEP
Se
ts the horizontal timing offset up/down step increment in units of
microseconds. You can use "MIN", "MAX", or "DEF" instead of numeric
values.
:SOURce:CORRection:MDELay :VERTical
Sets the vertical timing offset of the genlock signal relative to the internal
reference signal, in units of lines. Range: NTSC -±525, PAL - 625, HD -
562, or ±375 (720p).
:SOURce:CORRection:MDELay :VERTical:STEP
Sets the vertical timing offset up/down step increment in units of lines. You
can also use "MIN", "MAX" or "DEF" instead of numeric values.
:SOURce:TIMESet:OFFSet <nume ric_value>,<numeric_value>
(HH:MM)
Sets the global time offset (from system TOD). This command can b e used to
adjust time for a time zone.
:SOURce:TIMESet:OFFSet?
Returns the global time offset.
