Tektronix TG8000 Programmer's Manual

AGL7 Analog Genlock module remote commands
SOURCE comman
ds
Use these commands to set the timing offset of the genlock input signal relative
to the internal reference signal (frame reset signal).
Refer to Operating Basics in the TG8000 User Manual for detailed information
about the setting range.
Command tree
:SOURce
:CORRection
:MDELay
:HORizontal <numeric_value>
:STEP
<numeric_value>
:VERTical <numeric_value>
:STEP
<numeric_value>
Command d escription
:SOURce:CORRection:MDELay :HORizontal <numeric_value>
Sets the horizontal timing offset of th e genlock input signal relative to the
internal reference signal. The units are microseconds. You can use UP,
DOWN, or DEF instead of a numeric value.
:SOURce:CORRection:MDELay :HORizontal?
Returns the horizontal timing offset of the genlock input signal.
:SOURce:CORRection:MDELay :HORizontal:STEP <numeric_value>
Sets the step increment used by the UP or DOWN command. The units are
microseconds. You can use MIN, MAX, or DEF instead of a numeric value.
:SOURce:CORRection:MDELay :HORizontal:STEP?
Returns the step increment used by the UP or DOWN command.
:SOURce:CORRection:MDELay :VERTical <numeric_value>
Sets the vertical timing offset of the genlock input signal relative to the
internal reference s ignal. The units are line numbers. You can use UP,
DOWN, or DEF instead of a numeric value.
:SOURce:CORRection:MDELay :VERTical?
Returns the vertical timing o ffset of the genlock input signal.
:SOURce:CORRection:MDELay :VERTical:STEP <numeric_value>
Sets the step increment used by the UP or DOWN command. The units are
line numbers. You can use MIN, MAX, or DEF instead of a numeric value.
:SOURce:CORRection:MDELay :VERTical:STEP?
Draft
34 TG8000 Multiformat Test Signal Generator Programmer Manual
