Tektronix TG8000 Programmer's Manual

AWVG7 Analog Wideband Video Generator module remote c ommands
AWVG7 Analog W
ideband Video Generator module remote
commands
This section describes the remote commands used to control the AWVG7 Analog
Wideband Video Generator module remotely. The commands to the module are
divided int
o the following three groups:
MASS MEMORY commands (Refer to the TG8000 Multiformat Test Signal
Generator User Manual)
OUTPUT commands
SENSE commands
MASS MEMORY commands
Two MASS MEMORY commands are listed here for your reference. You can
use these to load and query the output test signal. Detailed information for using
these commands are located in the TG8000 Multiformat Test Signal Generator
User Manual.
:MMEMory:LOAD:SIGNal <module_ name>,<signal_name>
:MMEMory:LOAD:SIGNal <slot_nu mber>,<signal_name>
Loads a signal into the specified module.
:MMEMory:SIGNal:ACTive <slot_ number>|<module_name>
Returns the current output signal of the specified module.
OUTPUT commands
Use these commands to control the output parameters of the m odule. These
include output status and circle/text/logo overlay.
Command tree
:OUTPut<n>
:STATe
ON|OFF
:CIRCle
:STATe
ON|OFF
:DIAMeter
<numeric_value>
:POSition
:HORizontal <numeric_value>
:VERTical <numeric_ value>
Draft
TG8000 Multiformat Test Signal Generator Programmer Manual 53
