AGL7 Analog Genlock module remote commands
Sets the video s
tandard for the BLACK 3 output. The choices are BB (black
burst) and HD1080_60I to HD720_50P.
:OUTPut3:STA
Ndard?
Returns the video standard for the BLACK 3 output.
:OUTPut<n>:SIGNal BB|BB_FREF |BB_NO_FREF
Sets what kind of signal is available from a specific BLACK output. The <n>
in the command represents the connector number. You can use connector
number 1 and 2.
If the standard is NTSC or NTSC_NSU, the options are BB (black burst) or
BB_FREF (black burst with field reference).
If the standard is PA L, the options are BB (black burst) or BB_NO_FREF
(black burst no field reference).
:OUTPut<n>:SIGNal?
Returns the current output signal. The <n> in the command represents the
connector number. You can use connector number 1 and 2.
SENSE
commands
Use these commands to set the timing offset of the BLACK outputs relative to the
internal reference signal (frame reset signal).
Refer to Operating Basics in the TG8000 User Manual for detailed information
about the setting range.
Com
mand tree
:SENSe<n>
:CORRection
:MDELay
:HORizontal <numeric_value>
:
STEP
<numeric_value>
:VERTical <numeric_value>
:STEP
<numeric_value>
Draft
36 TG8000 Multiformat Test Signal Generator Programmer Manual
