Tektronix TG8000

ATG7 Analog Test Generator m odule remote commands
ATG7 Analog Te
st Generator module remote commands
This section
describes the command set s used for the ATG7 Ana log Test
Generator module remote operation. The commands for the module are divided
into the following three groups:
MASS MEMORY commands (Refer to the TG8000 Multiformat Test Signal
Generator User Manual)
OUTPUT commands
SENSE commands
MASS MEMORY commands
Two MASS MEMORY commands are listed here for your reference. You can
use these to load and query the output test signal. Detailed information for using
these commands are located in the TG8000 Multiformat Test Signal Generator
User Manual.
:MMEMory:LOAD:SIGNal <module _name>,<signal_name>
:MMEMory:LOAD:SIGNal <slot_n umber>,<signal_name>
Loads a signal into the specified module.
:MMEMory:SIGNal:ACTive <slot _number>|<module_name>
Returns the current output signal of the specified module.
OUTPUT commands
Use these commands to control the output parameters of the module. These
include ID text overlay and APL features.
Command tree
:OUTPut<n>
:STANdard NTSC|NTSC_NSU|PAL
:SIGNal BB | BB_FREF | BB_NO_FREF |
SYNC | BLANKING | SUBCARRIER
| H_DRI VE | V_DRIVE | FREF |
PAL_PULSE (n=1,2)
BB | BB_NO_FREF | CB100_PER
| CB75_ PER | CB_SMPTE |
FF40PER | CB100_ OR | CB75_OR
| OTHER_ONE | OTHER_TWO (n=4)
:OVERlay
