Tektronix TG8000 Programmer's Manual

ATG7 Analog Test Generator module remote commands
:BLINk
:STATe
ON|OFF
:PERiod <numeric_value>
:TEXT
:STATe
ON|OFF
:DATA
<string>
:POSition
:HORizontal <numeric_value>
:VERTical <numeric_value>
:SAVe
:APL
:MODe
APL_OFF | APL_HIGH | APL_LOW
| APL _BOUNCE
:PERiod <numeric_value>
Command description
:OUTPut<n>:STANdard NTSC|NTSC _NSU|PAL
Sets the video standard for the BLACK 1, BLACK 2, or BARS output. The
choices are NTSC, NTSC_NSU (NTSC no setup), or PAL. The <n> in the
command represents the output connector type and you can specify 1, 2, or
4. "1" represents the BLACK 1 connector, "2" represents the BLACK 2
connector, and "4" represents the BARS connector.
:OUTPut<n>:STANdard?
Returns the video standard for the BLACK 1, BLACK 2, or BARS output.
The <n> in the command represents the output connector and you can specify
1, 2, or 4. "1" represen
ts the BLACK 1 connector, "2" represents the BLACK
2 connector, and "4" represents the BARS connector.
:OUTPut<n>:SIGNal B
B|BB_FREF|BB_NO_FREF|SYNC|BL ANKING|
SUBCARRIER|H_DRIVE|V_DRIVE |FREF| PAL_PULSE
(n=1,2) BB|BB_NO_FREF|CB100_P ER|CB75_PER|CB_SMPTE|
FF40PER|CB100_OR|CB75_OR|O THER_ONE| OTHER_TWO (n=4)
Sets the signal available from the BLACK 1, BLACK 2, or BARS output.
The <n> in the command represents the output connector and you can specify
1, 2, or 4. "1" represents the BLACK 1 connector, "2" represents the BLACK
2 connector, and "4" represents the BARS connector.
If "1" or "2" is specified for the connector type, the choices are BB (black
burst), BB_FREF (black burst with field reference), BB_NO_FREF (black
burst no field re f
erence), SYNC (composite sync), BLANKING (composite
blanking), SUBCARRIER (subcarrier), H_DRIVE (H drive), V_DRIVE (V
drive), FREF (Color Frame ID), or PAL PULSE (PAL pulse).
Draft
TG8000 Multiformat Test Signal Generator Programmer Manual 39
