Tektronix TG8000

HD3G7 3 Gb/s SDI Video Generator module remote commands
:MODe
MODE_3GA|MODE_3GB| MODE_3GB_2K |
MODE_3GA_2K|MD_720 _3GA|MD_2X1 080_HD|
MD_2X720_HD|MD_108 0_HD|MD_720 _HD
:MODe?
:STANdard HD1080_60P|
HD1080_59P|HD1080_ 50P|
HD1080_60I|HD1080_ 59I|HD1080_ 50I|
HD1080_30P|HD1080_ 29P|HD1080_ 25P|
HD1080_24P
|HD_1080_23|HD1080_ 30SF|
HD1080_29SF|HD1080 _25SF|HD108 0_24SF|
HD1080_23SF|
HD720_60P
|HD720_5994P|HD720_5 0P|
HD720_30P|HD720_29 97P|HD720_2 5P|
HD720_24P|HD720_23 98P|
TK1080_23
P|TK1080_23SF|TK1080 _24P|
TK1080_24SF|TK1080 _25P|TK1080 _25SF|
TK1080_29P|TK1080_ 29SF|TK1080 _30P|
TK1080_3
0SF
:STANdard?
:SAMPling
:SELect
GBR444_12B|GBR444_1 0B|GBR444A_ 10B|
YCB444_12B|YCB444_1 0B|YCB444A_ 10B|
YCB422_12B|YCB422_1 0B|YCB422A_ 12B|
XYZ444_2K
:SAMPling?
:VIDeo
:Y
:STATe
ON|OFF
:STATe?
:PB
:STATe
ON|OFF
:STATe?
:P
R
:STATe
ON|OFF
:STATe?
:AVTiming
:State
ON|OFF
:State?
:EFILter
ON|OFF
:EFILter?
:State
ON|OFF
:State?
:MOVe
:HORizontal <numeric_value>
:HORizontal?
Draft
TG8000 Multiformat Test Signal Generator Programmer Manual 101
