HDVG7 HDTV Digital Video Generator module remote commands
:STATe
ON|OFF
:STANdard HD1080_60I|HD108 0_59I|HD1080 _50I|
HD1080_24SF|
HD1080_23SF|HD1080_3 0P|
HD1080_29P|HD1080_2 5P|HD1080_2 4P|
HD1080_23P|HD1035_6 0I|HD1035_5 9I|
HD720_60P|H
D720_59P|HD720_50P|
HD720_30P|HD720_29P |HD720_25P|
HD720_24P|HD720_23P
:SIGNal BLACk|GRAY|FF50P |WHITe
Command description
:OUTPut1:CIRCle:STATe ON|OFF
Turns the circle overlay on the video signal on or off. You can use 1 or
0 instead of ON or OFF.
:OUTPut1:CIRCle:STATe?
Returns the current circle overlay state.
:OUTPut1:CIRCle:DIAMeter <num eric_value>
Sets the diameter of the displayed circle. The unit is percent of active picture
height. You can set the diameter from 0% to 100% in 1% steps. You can also
use MIN, MAX, or DEF instead of a numeric value.
:OUTPut1:CIRCle:DIAMeter?
Returns the diameter of the displayed circle.
:OUTPut1:CIRCle:POSition:H ORizontal <numeric_value>
Sets the horizontal position of the circle as it appears on the active signal.
The unit is percent of active picture width. You can set the position from
-50% to +50% in 1% s teps. You can also use MIN, MAX, or DEF instead of
a numeric value.
:OUTPut1:CIRCle:POSition:H ORizontal?
Returns the current horizontal position of the circle as it appears on the active
signal.
:OUTPut1:CIRCle:POSition:V ERTical <numeric_value>
Sets the vertical position of the circle as it appears on the active signal. The
unit is percent of active picture height. You can set the position from -50%
to +50% in 1% steps. You can also use MIN, MAX, or DEF instead of a
numeric value.
:OUTPut1:CIRCle:POSition:V ERTical?
Returns the current vertical position of the circle as it appears on the active
signal.
:OUTPut<n>:EAUDio:CHANnel< m>:AMPLitude <numeric_value>
Draft
TG8000 Multiformat Test Signal Generator Programmer Manual 137
