MX32v2
ANALOG AND DIGITAL CONTROLLER
USER MANUAL
Revision D.0
E – Module configuration DIP switchesDIP switches are set according to the following table:
Slave number
Numéro esclave
See details in the paragraph
Module Address
on page 22
Frame filling
Remplissage de trame
Factory settings. Do not modify
Temporisation
Factory settings. Do not modify
E.O.L. Resistor
Résistance F.D.L.
See details in paragraph
End of line Resistor,
on page 24
Table 8: Configuration DIP switches of the
Analog Input Module
5.6.3 Connection
Refer to Chapter 6, on page 33
5.6.4 Configuration
Configured via the
COM 32
application
Note related to manual calibration of the detectors connected to an 8-analog input module.
1. Zero calibration
Inject zero grade air to obtain 4 mA. Place the multimeter between points E and D (Figure
19). If the value measured is different from 0 V, adjust C.
2. Sensitivity calibration
After applying gas, place the multimeter between points E and D (Figure 19). If the value
measured is different from 1.6 V, adjust B.
Should the adjustment value be different, calculate:V= I (mA) x 0.10 (V/mA)
Example: If the current is 12 mA, “V” must be equal to 0.8 V
