MX32v2
ANALOG AND DIGITAL CONTROLLER
USER MANUAL
Revision D.0
7.7.4 Operating mode
Detector selection
1. Select the detector to be calibrated with the help of the Previous detector and Next
detector keys and press Validate.
Zero calibration
1. The Zoom command is active.
2. Select the area of interest of the curve with the and keys. Press Zoom + up to the
activation of the Zero command. Adjust the position of the cursor so as to make the
“OK” appear, in turn indicating that the range selected is sufficiently stable.
3. Press to select the term Zero.
4. Confirm the zero calibration by pressing Validate zero.
5. The term Sens (for sensitivity) is active from now on.
If sensitivity is not to be calibrated, press and END; until you see the message “Do
you only want to calibrate zero for the detector?”, then press Validate calibration. Only
the zero calibration of the detector will have been carried out.
If sensitivity is to be calibrated, proceed directly to the following paragraph.
Sensitivity calibration
1. The Sens command is active.
2. Select the area of interest of the curve with the and keys. Press Zoom + up to the
activation of the command Sens. If applicable, adjust the position of the cursor so as to
make the “OK” appear, in turn indicating that the range that has been selected is
sufficiently stable.
3. Confirm the sensitivity calibration by pressing Validate Sens.
Record the calibration
1. The message “Do you want to validate zero and detector sensitivity?” is displayed. Press
Validate calibration to confirm the adjustment of zero and sensitivity or Esc to exit the
procedure.
2. The detector is calibrated.
