51
The letter “S” appears on the line if the events were obtained when the MX32v2 was in simulation
modeDelete deletes all the data. Up to 512 events can be memorized. Beyond that, the most
recent event deletes the oldest. Previous page, Next page, and Last page access the
corresponding pages of the file.
Message
Significance
AL1 Detector in level 1 alarm
AL2 Detector in level 2 alarm
AL3 Detector in level 3 alarm
OVS Detector in OVS alarm
AL1 M
Detector in alarm set to level 1 mean value
AL2 M
Detector in alarm set to level 2 mean value
AL3 M
Detector in alarm set to level 3 mean value
Table 11: Gas alarm file messages.
2. Fault records
This displays, for each detector concerned: event type (UDS = Under-scale), RANGE =
measurement out of range, DEF =Failure, DOUBT = clear doubt), status (activated = ON or
deactivated = OFF) as well as the date and time of appearance or release. This file cannot be
deleted.
Message
Significance
UDS
The measurement is lower or equal to the value of the UDS programmed.
DEF
Detector failure (out of range, line cut, defective cell, etc.).
RANGE Measurement out of range.
>> LEL Concentaration higher than 100% of LEL.
Table 12: Failure file messages
3. Inputs and relays records
This displays, for each relay and logic input concerned: activated relay/input ID, type (REL =
relay, EL = Logic input), its status (activated = ON, Deactivated = OFF) as well as the date and
time of occurrence or release.Delete allows for the deletion of this entire file. Up to 512 events
can be memorized. Beyond that, the most recent event deletes the oldest. Previous page, Next
page, and Last page access the corresponding pages of the file.
