Message
Significance
RELAY Status change of the designated relay.
INPUT Status change of the designated input.
Table 13: Relay and logic input file messages.
4. Working conditions records
This displays the actions carried out on the MX32v2 (simulation mode, calibration mode,
programming mode, release request, operation on internal battery), as well as the date and
time of beginning and end of the event.Delete allows for the deletion of this entire monitoring
file. Up to 512 events can be memorized. Beyond that, the most recent event deletes the oldest.
Previous page, Next page, and Last page allow access to the corresponding pages of the
file; each page can display a maximum of 8 lines.
Message
Significance
Line 1 On/Off Start or stop line 1
Line 2 On/Off
Start or stop line 2
Detectors On/Off
Start or stop the detector
External ack.
Press the external acknowledgement button
MX32v2 ack Acknowledgement by the acknowledgement button on the front plate of
MX32v2
Simulation
Switch to simulation mode
Calibration
At least one of the detectors is selected in calibration mode.
Test detectors
Switch to test mode
Program Programming done on MX32v2
Time settings Time settings on MX32v2
Table 14: Operation monitoring file messages.
5. Hardware troubles records
This displays, for each material incident detected: incident ID, status (activated = ON or
deactivated = OFF) as well as the date and time of occurrence or release of the event.Previous
page, Next page, and Last page allow access to the corresponding pages of the file: each
page can display a maximum of 8 lines.
