MX32v2
ANALOG AND DIGITAL CONTROLLER
USER MANUAL
NP32V2EN
Revision D.0
53
Message
Significance
DEAD
Digital module no longer responding (line cut, module failure, wrong address,
module absent).
MODUL Configuration or module address error.
TEMP+ Internal temperature of the MX32v2 higher than maximum tolerated value.
TEMP- Internal temperature of the MX32v2 lower than maximum tolerated value.
LINE 1
Incident on line 1 (short-circuit).
LINE 2
Incident on line 2 (short-circuit).
CAL O
Calibration defect (zero shifted).
CAL S Calibration defect (used cell).
CAL F Calibration defect (cell oversensitive).
CAL D Calibration defect (measurement unstable).
Table 15: Material incidents file messages
6. System troubles records
This displays the events relative to MX32v2 operation (power failure/fluctuation, On/Off,
etc.).Previous page, Next page, and Last page allow access to the corresponding pages of
the file; each page can display a maximum of 8 lines.
Message
Significance
ON
MX32v2 on live voltage
OFF
MX32v2 off voltage
Self-testing
failure
Failure of internal tests
Other
messages
Contact Post-Sales Service
Table 16: System incidents file messages
7.9.2 3. Slave info
These data enable maintenance technicians to visualize the communication framework between
MX32v2 and the digital modules.
7.9.3 4. Controller info
These data allow technicians to visualize different counters such as number of resets on low
voltage input, error system, configuration, etc.
