MX32v2
ANALOG AND DIGITAL CONTROLLER
USER MANUAL
Revision D.0
12.3.2 Configuring sensors
Downloading the configuration
The
MX32v2
uses 64 external addresses (line #1 channel #1, to line #2 channel #32) and 2
analog channels for which the addresses are located from 257 to 258.
With the automated system, it is possible to send 66 (64 + 2)
Modbus
requests, where the
address field is numbered from 1 to 64 then from 257 to 258 in order to download the
configuration of each sensor into the internal memory.
As a result of the operating functionality, it is only possible to repatriate the data of a single
sensor for interrogation.
If a sensor is stated at the address mentioned, the
MX32v2
sends the number of data words
requested; always from data #1: NAME OF ANALOG SENSOR, at data #x.
If there is no information at the address mentioned, the
MX32v2
sends back 0.
1
Line 1 Sensor 1
32
Line 1 Sensor 32
33
Line 2 Sensor 1
64
Line 2 Sensor 32
257
Analog line #1
264
Analog line #2
Sensor addresses
