Address
SENSORS
[64 + 2]
Nb
bytes
Data type
1 Com sensor
2 X
16
Unicode text (16 bits) 16
characters including the
final /0.
17 Status 2 Start / Stop: if in
operation, variable = 1. If
stopped, variable = 0.
18 Gas name
2 x
20
Unicode text (16 bits) 20
characters including the
final /0.
38 Range 2 Value The range is from 1
to 5000.
Range X 10 display
format.
The display format is given
in another box.
39
Display
format
2 Coded value.
40 Unit 2 X 5
Unicode text (16 bits) 5
characters including the
final /0.
45
Abbreviated
gas name
2 x 6
Unicode text (16 bits) 6
characters including the
final /0.
CAUTION, if the first 2
letters = O2: special
treatment.
51 Zone 2 Value 1 to 8
52
Instantaneou
s alarm
threshold 1
2 Value
-999 to 9999 (real value to
be multiplied like the range)
53 Instantaneou
s alarm
threshold 2
2 Value -999 to 9999 (real value to
be multiplied like the range)
54
Instantaneou
s alarm
threshold 3
2 Value
-999 to 9999 (real value to
be multiplied like the range)
55 Average
alarm
threshold 1
2 Value -999 to 9999 (real value to
be multiplied like the range)
56
Average
alarm
threshold 2
2 Value
-999 to 9999 (real value to
be multiplied like the range)
57 Average
alarm
threshold 3
2 Value -999 to 9999 (real value to
be multiplied like the range)
58
Underscale
threshold
2 Value
-999 to 9999 (real value to
be multiplied like the range)
