MX32v2
ANALOG AND DIGITAL CONTROLLER
USER MANUAL
74
NP32V2EN
Revision D.0
Address
SENSORS
[64 + 2]
Nb
bytes
Data type
59
Overscale
threshold
2 Value
-999 to 9999 (real value to
be multiplied like the range)
60
Default low
threshold
2 Value
-999 to 9999 (real value to
be multiplied like the range)
61
Out of range
threshold
2 Value
-999 to 9999 (real value to
be multiplied like the range)
62
Integration
time alarm 1
2 Value
15 - 480 min per 1min step
(if not used, put 15 min)
63
Integration
time alarm 2
2 Value..
15 - 480 min per 1min step
(if not used, put 15 min)
64
Integration
time alarm 3
2 Value
15 - 480 min per 1min step
(if not used, put 15 min)
65 Hysteresis 2 Value
Caution, max = 5% of the
range. Always use a positive
value and not a percentage.
66
Alarm
active?
2 Configuration per bit Al active inst, avg: 1, 2, 3. bit6 bit5 bit4 bit3 bit2 bit1 bit0
0 = inactive
1 = active
Alarm avg 3
Alarm avg 2
Alarm avg 1
Alarm inst 3
Alarm inst 2
Alarm inst 1
67 Acknowl
alarm?
(Auto/manu)
2 Configuration per bit Manual acknowl Al 1, 2, 3,
verification
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit
0
Verification
1 = Manual acknowl and 0
= Automatic Acknowl.
When the
Verification is at
1, the
Verification alarm,
once activated, is
deactivated by stopping the
sensor.
If the acknowledgment is
manual, alarms 1, 2 or 3,
once activated, are
deactivated using the
acknowl button +
measurement < alarm.
1 = verification
put 0 mandatory put 0 mandatory
put
1
mandatory
put 0 mandatory
1=Al3 ackmanu 1=Al2 ackmanu 1=Al1 ackmanu
68 Increasing or
decreasing
alarm?
2 Configuration per bit Al 1, 2, 3 instantaneous or
average increasing or
decreasing
1: increasing
0: decreasing
Alarm avg 3
Alarm avg 2
Alarm avg 1
Alarm inst 3
Alarm inst 2
Alarm inst 1
