12.3.3 Acquisitions retrieved cyclically
Real address
SENSOR
MEASUREME
NTS [256 +
8]
Nb bytes
Data type
If digital
Start: 2001
end : 2064
If analog
Start: 2257
end : 2258
Sensor
measurement
2
Table with 66 signed integer of 16 bits where
the measurements are listed at their address.
The measurement being whole, the automatic
system uses the Display format
field to
determine where to position the comma.
Real address
ALARMS
[256 + 8]
Nb bytes
Data type
If digital
Start: 2301
end : 2364
If analog
Start: 2557
end : 2558
Table of
activated
alarms
2
Table with 66 signed integers of 16 bits where
the alarms bits are listed at their address.
ALARM_1 (bit 0)
ALARM_2 (bit 1)
ALARM_3 (bit 2)
UNDERSCALE (bit 3)
OVERSCALE (bit 4)
AL_DEFAULT (bit 5)
AL_OUT_OF_RANGE (bit 6)
L_VERIFICATION (bit 7)
Bits 8 to 16 not in use
Real address
INFO
Nb bytes
Data type
2600
CRC32 of the
general
configuration
2 32 most significant bits option.
Note: CRC32 of the entire configuration
except the relays (from 0x78000 to
0x7AFFC). If different, re-
upload the
configuration.
2601 2 32 least significant bits option.
2602
Second
counter
2
32 most significant bits option;
Note: this counter increases every second and
verifies that the unit is active.
2603 2 32 least significant bits option.
