Tenda PON ONT HG9 User Manual

Get to know your device
5
HG7 & HG7c
The appearance of HG7 and HG7c is quite similar, except that HG7c does not have the TEL indicator
and port. The following figures show the appearance of HG7 as an example.
◼ LED indicators
HG7
LED
indicator
Color
Status
Description
PWR
Green
Solid on
The ONT is powered on properly.
Off
The ONT is powered off or not powered on properly.
PON
Green
Solid on
The ONT is registered successfully.
Blinking
The registration is not completed (unregistered or registering).
Off
The received optical power is lower than the optical receiver
sensitivity, or no fiber cord is connected.
LOS
Red
Blinking
The received optical power is lower than the optical receiver
sensitivity, or no fiber cord is connected.
Off
The received optical power is within the optical receiver sensitivity.
LAN
Green
Solid on
There is at least one LAN port connected properly, but no data is
being transmitted over the corresponding port.
Blinking
There is at least one LAN port connected properly, and data is being
transmitted over the corresponding port.
Off
No Ethernet device is connected or the Ethernet device is not
connected to any LAN port properly.
2.4G/5G
Green
Solid on
The 2.4 GHz/5 GHz Wi-Fi network is enabled, but no data is being
transmitted wirelessly.
Blinking
slowly (0.5s)
The 2.4 GHz/5 GHz Wi-Fi network is enabled, and data is being
transmitted wirelessly.
Blinking
quickly
(0.25s)
The ONT is performing or pending for WPS negotiation.
Off
The 2.4 GHz/5 GHz Wi-Fi network is disabled.
TEL
Green
Solid on
The ONT is registered with IMS, but no data is being transmitted.
Blinking
The ONT is registered with IMS, and data is being transmitted.
Off
The ONT is not registered with IMS.
