Get to know your device
7
HG9
LED indicators
LED indicator
Color
Status
Description
POWER
Green
Solid on
The ONT is powered on properly.
Off
The ONT is powered off or not powered on properly.
INET
Green
Solid on
Internet access is available via the ONT.
Blinking
Data is being transmitted via the ONT.
Off
No internet access is available via the ONT.
PON
Green
Solid on
The ONT is registered successfully.
Blinking
The registration is not completed (unregistered or registering).
Off
The received optical power is lower than the optical receiver
sensitivity, or no fiber cord is connected.
LOS
Red
Blinking
The received optical power is lower than the optical receiver
sensitivity, or no fiber cord is connected.
Off
The received optical power is within the optical receiver sensitivity.
LAN1/2/3/4
Green
Solid on
The LAN port is connected properly, but no data is being transmitted
over the corresponding port.
Blinking
The LAN port is connected properly, and data is being transmitted
over the corresponding port.
Off
No Ethernet device is connected or the Ethernet device is not
connected to the LAN port properly.
TEL
Green
Solid on
The ONT is registered with IMS, but no data is being transmitted.
Blinking
The ONT is registered with IMS, and data is being transmitted.
Off
The ONT is not registered with IMS.
2.4G/5G
Green
Solid on
The Wi-Fi network of the corresponding frequency is enabled, but no
data is being transmitted wirelessly.
