Config MSTP modification level. Valid range is
0-65535. The default is 0.
A value worked out by VLAN mapping,
belonging to an important parameter of the
inter-domain calculation.
MSTP Instance
Click Device Management -> STP -> MSTP Instance to enter interface below:
Fields on the screen are described below:
Instance ID: 0-15. 0: the inter-domain spanning
tree.
Enable/Disable the corresponding selected
instance. Only instance 0 is enabled by default
and can’t be disabled.
Display instance's current mapping VLANs.
Display instance's current bridge priority.
To configure a single instance, click the corresponding instance to enter interface below:
To Next Page
