7. CUP HOLDER 24. HYDRAULIC REMOTE CONTROL
TRANSMISSION SWITCH (Option)-See
Hydraulic Remote Control section for
operation.
8. FRONT JACK INDICATOR-Red light "ON"
indicates the front jack is "NOT" retracted.
25. HYDRAULIC REMOTE POWER SWITCH
(Option)-See Hydraulic Remote Control
section for operation.
9. VOLTMETER-Guage indicates battery or
alternator condition.
26. HYRAULIC REMOTE CONTROL
STEERING SWITCH (Option)-See Hydraulic
Remote Control section for operation.
10. WAIT TO START-Red colored Warning
Light "ON". Do not engage Engine starter
until light goes "OFF".
27. OUTRIGGER EXTEND/RETRACT
MASTER SWTICH-Switch is actuated before
the Outrigger Swtiches (19) (20) (21) (22) to
Extend or Retract the outrigger beams and
jacks. Push switch left to retract and right to
extend.
11. ENGINE COOLANT TEMPERATURE
GUAGEGuage and Red colored Warning
Light "ON" when engine is at 230 degrees
Farenheit (110 C) or above. Engine is
overheating..
28. IGNITION SWITCH
A. All circuits "off".
B. Circuits other than ignition "on".
C. All circuits including ignition "on".
D. Engine "start".
12. SWING LOCKED INDICATOR-Red light
"ON" indicates the superstucture is locked
and will not rotate.
29. ACCELERATOR-Push to increase engine
RPM and release to decrease.
13. TACHOMETER-Guage indicates Engine
RPM.
30. BOOM EXTEND/RETRACT PEDAL-Tilt
the pedal halfway forward to power-extend
the boom. Tilt the pedal all the way forward
for high speed (regenerative) extend. The
boom extend will stop at the transition
between power extend and high speed. In
high speed the boom extend has minimal
extend force. Tilt pedal backward to retract
the boom.
14. GREER LMI DISPLAY-See RCI510
Operators Manual for operation.
31. SWING BRAKE-Apply to prohibit the
boom from swinging. This is a dynamic
friction brake and can be feathered to slow
boom swing during operation, or can be
locked into postion via the (32) Swing Brake
Release knob above on the dash panel.
Always set the Swing Lock (33) when
transporting the machine or exiting the cab.
127P/N 12261-683 REVISED: January 2015
