Outriggers
T300-1 & T500-1 -Use single beam outriggers as shown below.
1. Hose Disconnects
2. Wear Pad
3. Outrigger Extend Cylinder Deadend
T780-Use a double beam outrigger as shown below.
441P/N 12261-683 REVISED: January 2015
