Terex T780 - Air-Ride Suspension

On-Tires Load Rating Chart
ON TIRES
RADIUS (FT) MAX BOOM LENGTH (FT) BOOM STRAIGHT OVER
REAR
0 TO 2 1/2 MPH
10 30 13,900
12 30 12,600
15 39 10,600
20 39 7,400
25 50 5,100
30 50 3,300
35 50 1,900
40 50 1,000
T300-1_T500-1_T780
Operating Instructions
204 P/N 12261-683
REVISED: January 2015
