Terex T780 - Hoist-Line Reeving

Hoist-Line Reeving
1. AUXILIARY WINCH 2. MAIN WINCH
3. 5 SHEAVE 4. 4 SHEAVE
5. DEAD END FOR EVEN PARTS OF LINE 6. DEAD END FOR ODD PARTS OF LINE
7. WINCH DEAD END 8. IDLER SHEAVE
9. LOAD SHEAVE 10. BLOCK SHEAVE
11. CABLE SOCKET
