- on outriggers (fully extended & partially extended) with jib erected, jib pullout section
extended, lifting over the jib pullout section
- on tires, lifting over main boom with jib stowed
6.
If the auxiliary boom head is not erected, add 100 lbs to the chart rated capacity.
7.
Compare load weight with chart rated capacity from the boom length, radius, and
boom angle.
8. The lifted load must not exceed the chart rated capacity for the boom length and radius.
In this example, the lifted load of 19,575 lbs is less than the rated load of 28,300 lbs and
can be handled.
201P/N 12261-683 REVISED: January 2015
