DESCRIPTION OF MOVEMENT
B2 MOVE SLOWLY. Use one hand to give any motion signal and place other hand motion-
less in front of hand giving the motion signal. (Hoist slowly shown as example)
B3 RAISE THE BOOM AND LOWER THE LOAD. With arm extended, thumb pointing up,
flex fingers in and out as load movement is desired.
B4 LOWER THE BOOM AND RAISE THE LOAD. With arm extended, thumb pointing
down, flex fingers in and out as long as load movement is desired.
B5 SWING. Arm extended, point with finger in direction of swing of boom.
C1 STOP. Arm extended, palm down, move arm back and forth horizontally.
C2 EMERGENCY STOP. Both arms extended, palms down, move arms back and forth
horizontally.
C3 TRAVEL. Arm extended forward, hand open and slightly raise, make pushing motion
in direction of travel.
C4 DOG EVERYTHING. Clasp hands in front of body.
C5 TRAVEL (Both Tracks). Use both fists in front of body, making a circular motion about
each other, including direction of travel, forward or backward.
D1 TRAVEL (One Track). Lock the track on the side indicated by raised fist. Travel
opposite track in the direction indicated by the circular motion of other fist, rotated
vertically in front of the body.
D2 EXTEND BOOM. (Telescopic Booms). Both fists in front of body with thumbs pointing
outwards.
D3 RETRACT BOOM. (Telescopic Booms). Both fists in front of body with thumbs
pointing outwards each other.
D4 EXTEND BOOM (Telescopic Booms). ONE HAND SIGNAL. One fist in front of chest
with thumb tapping chest.
D5 RETRACT BOOM (Telescopic Booms). ONE HAND SIGNAL. One fist in front of chest,
thumb pointing outward and heel of fist tapping chest.
