Allison Transmission Filters
3000 Series High Capacity Filter Kit (4 inch)-For Replacement or Service Order: Terex No.
222661
Kit contains the following items listed below:
ITEM NO. Allison PART NO. QTY. DESCRIPTION
1. 29545778 1 Instruction Sheet
#322
2. 23019664 1 O-Ring-Packing-
(drain plug)
3. 29524449 2 Gasket, Filter Cover
4. 29548953 2 O-Ring, Low Temp
(Rd. edge) See note
A) below
5. 29501469 2 Seal, Ring (Sq. cut)
6. 29507437 2 O-Ring, Packing
7. 29545780 2 Filter
NOTE: A) Only one style of item 4 & 5 is used. The kit is supplied with both old style
cut o-ring and new style round edge o-ring. If the filter cover is the old style it will be
machined for the square cut o-ring, if not, then you disgard the square cut and use
the new round edge or visa versa.
345P/N 12261-683 REVISED: January 2015
